Unlock the Precise Fit: Group 31 Battery Dimensions Explained for Reliable Power

If you need the short answer first, the most useful working size for a Group 31 battery is:

By Reid Callahan · 22 July 2026 · 19 min read

If you need the short answer first, the most useful working size for a Group 31 battery is:

13.0 inches long
6.8 inches wide
9.4 inches high
About 330 × 173 × 240 mm

That is the most repeated published baseline across reviewed battery charts, replacement references, and product specifications. It is the right starting point for shopping by case size.

The important qualifier is that Group 31 is a size class, not a promise that every battery label will show the exact same decimals. Across the reviewed material, Group 31 products cluster tightly around that footprint, but published width and height figures move slightly by manufacturer, terminal layout, and chemistry. Lithium examples, in particular, are often shorter in height while keeping a similar tray footprint.

This guide keeps those distinctions clear:

BCI Group 31 tells you the battery belongs to a standardized physical-size family.
It does not by itself tell you chemistry, amp-hours, cold-cranking power, or intended use.
The common market baseline is about 13 × 6.8 × 9.4 inches, but exact product dimensions still need to be checked before buying.

Because published references do not all print the same numbers, the article below separates three things that often get blurred together in shopping guides:

What the group number means
What dimensions most listings converge on
Where real-world products differ

What Defines a BCI Group 31 Battery?

A BCI battery group number is primarily a physical size designation. In practical terms, when a battery is labeled Group 31, it means the battery belongs to a standardized case-size family intended to fit applications built around that size.

That is the key point to understand before comparing products.

A Group 31 label does not automatically tell you:

whether the battery is flooded lead-acid, AGM, gel, or lithium
whether it is built mainly for engine starting, deep-cycle use, or dual-purpose duty
what exact CCA, reserve capacity, or amp-hour rating it will have
how much it weighs
whether its terminal layout matches your current cables

Capacity often correlates with a larger case, but it is not fixed by the group number alone. Two batteries can both be Group 31 and still differ meaningfully in:

amp-hour capacity
cold cranking amps
reserve capacity
weight
maintenance requirements
terminal orientation
intended application

So what does the designation actually buy you? Mostly fit guidance. It tells you the battery should fall within the same general case-size family and should be considered for the same tray space or battery box.

That is why Group 31 shows up so often in heavier-duty roles. Compared with smaller common groups, it usually offers a physically larger case, which often supports more stored energy or stronger starting performance depending on the battery design. In the reviewed material, Group 31 is repeatedly associated with applications such as:

marine starting and deep-cycle systems
RVs and campers
commercial trucks
off-grid and solar storage
industrial and utility equipment
backup power setups

This matters because shoppers often assume “Group 31” is almost a full specification. It is not. A better way to think about it is:

Group 31 means size family first. Everything else still has to be checked.

That is also why batteries with the same group number can still produce installation surprises. The tray may be right, but the battery may still be too tall for a lid, too heavy for easy handling, or wrong for your cable routing.

Standard Group 31 Dimensions: Inches and Metric

Across the reviewed battery references, the clearest working standard for group 31 battery dimensions is:

13.0” L × 6.8” W × 9.4” H 330 × 173 × 240 mm

That is the most useful answer for buyers because it reflects the strongest overlap among published charts and product listings. Some references print slightly different decimals, but they cluster very closely around the same overall envelope.

Group 31 dimension consensus table

The table below summarizes the repeated dimensions seen across published battery charts and product specs. It is best read as a market consensus baseline, not as a claim that every manufacturer prints the same figure.

Dimension	Consensus baseline	Common published range	Rounded metric equivalent
Length	13.0 in	12.9–13.0 in	330 mm
Width	6.8 in	6.72–6.81 in	173 mm
Height	9.4 in	9.27–9.50 in	240 mm

What the published ranges mean

When you compare reviewed battery charts and seller specifications, a pattern emerges:

Length is the most stable dimension at roughly 13 inches
Width usually lands between about 6.72 and 6.81 inches
Height varies the most, with standard-style listings commonly appearing between about 9.27 and 9.5 inches

That is why 13 × 6.8 × 9.4 inches is the best shorthand. It is precise enough to be useful, but still honest about the fact that published dimensions are not always identical to the hundredth of an inch.

Why inches and metric both matter

In U.S. battery replacement shopping, tray and box dimensions are often discussed in inches. But many battery listings, specification sheets, and imported products also publish case sizes in millimeters.

For Group 31, the most common metric baseline attached to the standard-size description is:

330 mm length
173 mm width
240 mm height

If you are comparing products sold in different markets, that metric translation is useful because it confirms you are still looking at the same general battery envelope.

The practical answer most buyers need

If someone asks, “What are the dimensions of a Group 31 battery?” the cleanest answer is:

About 13.0 × 6.8 × 9.4 inches, or 330 × 173 × 240 mm.

The word about matters. It reflects the real-world situation more accurately than treating one published decimal set as universal.

Dimension Variations by Manufacturer and Chemistry

Yes, Group 31 battery dimensions do vary slightly, even though the group itself is standardized.

The most noticeable variation in the reviewed material is usually height.

Where the variation shows up

Traditional lead-acid-style Group 31 listings usually stay close to the familiar baseline:

about 13 inches long
about 6.8 inches wide
about 9.4 inches high

But not every Group 31 listing sits at that full height. Published examples in the market also show shorter versions, especially among lithium products, with heights around:

8.43 inches
8.5 inches
8.7 inches

Those products still use a Group 31-style footprint, but they do not necessarily fill the same vertical space as a conventional lead-acid case.

Lead-acid vs. lithium size pattern

A useful market-level rule of thumb from the reviewed sources is:

Lead-acid Group 31 batteries usually stay very close to 13 × 6.8 × 9.4 inches
Lithium Group 31 batteries often keep similar length and width, but may be shorter in height

That shorter height can help if your clearance is tight under a lid or bracket. It can also create a new problem if your hold-down system was designed to clamp a taller battery.

In other words, a shorter lithium case may fit the space more easily, but it may not secure the same way.

Weight changes can be dramatic

Two batteries can share the same Group 31 family dimensions and still feel completely different in handling.

The reviewed market ranges cluster roughly like this:

Chemistry/type	Typical weight range
Flooded lead-acid	60–75 lb
AGM	62–72 lb
Lithium	22–35 lb

That difference matters in real installation terms.

A heavier battery can affect:

how hard it is to lift out of a tight compartment
how much stress a tray, slide, or mounting surface carries
how awkward routine maintenance becomes

A much lighter battery can affect:

how a hold-down clamps
whether the case shifts if not secured properly
whether an existing bracket was designed around a taller, heavier battery

Subgroups and terminal-layout differences

You may also run into subgroup-style naming such as 31R or other variants. In the reviewed material, those variations are generally associated more with:

terminal orientation
post position
application-specific layout

They do not necessarily mean the main case footprint is completely different. But they absolutely can change whether your battery cables reach cleanly and whether the hold-down clears the posts.

That is why “same group size” and “direct drop-in replacement” are not the same statement.

The fit takeaway

The most accurate way to say it is:

The Group 31 footprint is usually consistent
Minor case differences still happen
Height deserves special attention
Lithium versions are often shorter
Terminal layout still has to be verified

If your battery compartment is roomy, those variations may not matter much. If the battery sits under a cover, inside a battery box, under a seat, or near fixed cabling, they matter a lot.

Group 31 vs. Other Sizes: Size and Capacity Comparison

Group 31 is popular because it sits in a useful space: substantially larger than common mid-size groups like 24 and 27, but still far smaller than oversized battery classes like 8D.

For many buyers, the most relevant real-world comparison is Group 31 vs. Group 27.

Group 31 vs. Group 27 at a glance

A commonly cited Group 27 size reference is about:

12.06 inches long
6.81 inches wide
8.89 inches high

A common Group 31 baseline is about:

13.0 inches long
6.72 to 6.81 inches wide
9.44 inches high

In practical terms, that makes Group 31:

about 1 inch longer
about 0.5 inch taller
nearly the same width

Those differences sound small on paper, but they are large enough to affect a real installation. An extra inch of case length or roughly half an inch of added height is exactly the sort of change that can interfere with:

a battery-box lid
a crossbar hold-down
a tight engine-bay bracket
cable bend room above the posts

Capacity differences

The appeal of the larger case is that it often supports a higher-capacity battery package.

The reviewed material supports the following broad shopping ranges:

Group 24: about 70–85 Ah
Group 27: commonly treated as a middle step between Group 24 and Group 31, though published ranges vary by source and chemistry
Group 31: about 95–130 Ah in common lead-acid-style usage
8D: often around 225–260 Ah

Those are market-observed buying ranges, not BCI guarantees. Chemistry, battery design, and intended use still matter.

Quick comparison table

All figures below are approximate published shopping references rather than guaranteed values for every battery sold in each group.

Battery group	Typical dimensions (L × W × H)	Typical Ah range	Notes
Group 24	10.3 × 6.8 × 8.9 in	70–85 Ah	Smaller option where space and weight matter more
Group 27	about 12.1 × 6.8 × 8.9 in	Often positioned between Group 24 and Group 31; published ranges vary	Similar width to Group 31, but shorter and lower
Group 31	about 13.0 × 6.8 × 9.4 in	95–130 Ah typical in common lead-acid-style usage	Common heavy-duty marine, RV, truck, and deep-cycle size
8D	Much larger than Group 31	225–260 Ah	Oversized, high-capacity class that is also much heavier

When the size jump is worth it

Moving from Group 27 to Group 31 often makes sense when you want:

more reserve energy
longer accessory runtime
stronger support for house loads
a larger deep-cycle battery in the same general width class
more margin in heavy-demand starting applications

But it is not a swap to assume blindly. The size difference is small enough to tempt buyers into guessing and large enough to cause a return.

Typical Capacity, CCA, and Weight Specs

Once the case size is confirmed, most shoppers want to know what kind of performance numbers are common in the Group 31 market.

The best way to answer that is with ranges, not one fixed number.

Typical amp-hour capacity

Across the reviewed material, Group 31 capacity is best summarized like this:

Overall market range: about 75–130 Ah
Common lead-acid-style range: about 95–125 Ah
Lithium examples: commonly 100–140 Ah, with some published products reaching 165 Ah

Why the spread? Because Group 31 is a case-size family, not one battery design. A starting battery, a deep-cycle AGM, a gel battery, and a LiFePO4 battery can all fit the Group 31 envelope while offering very different usable energy.

That is also why it is important not to confuse:

size class
chemistry
performance role

They overlap, but they are not interchangeable terms.

Typical CCA range

For starting-oriented Group 31 batteries, the reviewed material repeatedly places CCA around:

800–1150 CCA

That range is most relevant for batteries sold for:

truck starting
marine starting
heavy-duty engine cranking
dual-purpose roles where starting performance matters

CCA is less useful as a main comparison tool for many deep-cycle lithium products, because those products are not always marketed or rated the same way.

So a practical buying distinction is:

If you need engine starting power, look closely at CCA
If you need runtime, look closely at amp-hours
If you need both, look for a battery explicitly sold for dual-purpose use

Typical weight

Weight is one of the biggest day-to-day differences inside the same Group 31 size family.

Battery type	Typical weight range
Flooded lead-acid	60–75 lb
AGM	62–72 lb
Lithium	22–35 lb

Some listings show slightly broader ranges, especially when comparing specific brands, but those bands are the most consistent across the reviewed material.

What these numbers mean in practice

These figures answer different questions:

Dimensions answer: Will it fit the space?
Amp-hours answer: How much stored energy is available?
CCA answers: How strong is cold-start performance?
Weight answers: How hard will it be to handle and secure?

A few common real-world scenarios make the distinction clear:

A lead-acid Group 31 deep-cycle battery may fit the tray perfectly but weigh enough to make removal awkward in a cramped compartment.
A lithium Group 31 battery may be much easier to lift and still fit the footprint, but its shorter height can change how the hold-down lands.
A starting-style Group 31 battery may post strong CCA numbers while not being the best choice for repeated deep discharge.

That is why Group 31 is best thought of as a size platform with multiple performance profiles available inside it.

Group 31 Battery Types and Their Fit

Group 31 batteries are sold in the major chemistries and use categories most buyers expect. The important thing is that they can belong to the same size family while behaving quite differently in service.

Main Group 31 battery types

Flooded Lead-Acid (FLA)

Traditional vented lead-acid batteries. These are common where upfront cost and broad compatibility matter most. In the reviewed material, they are generally among the heavier Group 31 options.

AGM

Absorbed Glass Mat batteries are sealed lead-acid batteries typically sold as maintenance-free. They are commonly chosen where vibration resistance and cleaner installation matter.

Gel

Gel batteries are another sealed lead-acid variation. They are often associated with deep-cycle use and specialized charging requirements.

LiFePO4 Lithium

Lithium iron phosphate batteries are widely sold in Group 31 format. They are typically much lighter than lead-acid batteries and often keep a similar length and width, though many published examples are shorter in height than traditional lead-acid Group 31 cases.

Same group size, different fit details

Although these battery types can all be sold as Group 31, their real-world fit is not identical in every sense.

Battery type	Common fit pattern	Practical fit note
FLA	Usually close to standard Group 31 height	Heavy; allow for lifting room and ventilation needs
AGM	Usually close to standard Group 31 case size	Heavy, but commonly chosen for vibration resistance
Gel	Similar Group 31 footprint	Verify charger compatibility as well as physical fit
LiFePO4	Often same length/width, sometimes shorter in height	Check hold-down position, terminal reach, and charging compatibility

Purpose categories matter too

Beyond chemistry, Group 31 batteries are also sold for different jobs:

Starting
Deep-cycle
Dual-purpose

That means two Group 31 batteries can be dimensionally similar but still be poor replacements for one another.

A battery can be:

the right size
and the wrong type

That is a common buying mistake.

The practical lesson

A Group 31 label tells you the battery belongs to the same broad size family. It does not confirm the same:

maintenance needs
charging requirements
terminal layout
reserve capacity
starting performance
hold-down behavior

If you are replacing like-for-like within the same chemistry and application, the process is usually straightforward. If you are changing chemistry or purpose, you need to check more than the tray footprint.

Common Applications for Group 31 Batteries

Group 31 batteries show up wherever users want more capacity or stronger starting support than smaller common groups usually provide.

Marine and boats

This is one of the most common Group 31 applications in the reviewed material. Boats may need support for:

engine starting
pumps
electronics
lighting
trolling loads
accessory draw over long outings

That makes Group 31 a common size for both starting and deep-cycle roles, depending on the battery design.

RVs and campers

In RV setups, Group 31 is popular because it offers a manageable footprint while often providing more capacity than smaller battery groups. It is commonly used for:

house battery banks
general onboard loads
inverter support
lighting and appliance power

Trucks and heavy-duty vehicles

Group 31 is also associated with larger trucks and work vehicles, especially where robust starting performance is required. This is where the stronger CCA figures commonly published for starting-style Group 31 batteries matter most.

Solar and off-grid systems

Deep-cycle Group 31 batteries are a common entry point for smaller off-grid and backup-power systems. The case size is familiar, widely available, and large enough to be useful without moving into very large industrial formats.

Industrial, agricultural, and utility equipment

Because Group 31 is a widely recognized heavy-duty size family, it also appears in:

industrial equipment
utility rigs
agricultural machinery
commercial power systems

Why this size is so common

The appeal is straightforward: Group 31 often gives users a useful balance of:

capacity
availability
fit compatibility
manageable size

It is large enough to serve demanding applications, but still small enough to fit many conventional battery boxes and vehicle compartments.

How to Measure and Verify Group 31 Fit

If the battery has to fit correctly the first time, the safest approach is to use the Group 31 standard dimensions as a starting point and then verify the actual installation space.

This section pulls the fit warnings into one process so you do not have to guess.

Step 1: Identify the battery you are replacing

Before measuring anything, confirm the current battery’s:

group number
chemistry
purpose category
terminal layout
polarity orientation

If your current battery is already a Group 31 and fits well, that is a strong clue. It is still not enough to skip measurement, especially if you are changing chemistry or manufacturer.

Step 2: Measure the tray or battery box

Measure the available space in three directions:

length
width
height clearance

Do not stop at the tray floor. Also check:

inside wall clearance
lid or hatch clearance
bracket interference
cable-bend room above the posts

For Group 31, the baseline target is about 13 × 6.8 × 9.4 inches, but published market specs show small variations. If the compartment is tight, shop to the product’s listed dimensions, not the group number alone.

Step 3: Check the hold-down system

A battery can fit the tray and still fail the installation because the hold-down does not land correctly.

Look at:

top crossbar position
side clamp location
battery-box strap path
the height the clamp expects

This is especially important if you are replacing a traditional lead-acid battery with a shorter lithium Group 31 case.

Step 4: Verify terminal placement and cable reach

Terminal layout matters as much as overall size.

Check:

positive and negative post location
whether you need a reversed-terminal variant
cable reach without strain
clearance from nearby metal parts, lids, or brackets

A battery that technically fits the tray but forces awkward cable routing is not a clean replacement.

Step 5: Treat published dimensions as a guide, not a guarantee

Across the reviewed material, standard-style Group 31 dimensions vary only slightly in length and width, but height moves the most. Lithium versions can be shorter still.

A practical rule is:

if your compartment is generous, the Group 31 baseline will often be enough
if your fit is tight, rely on the exact listing for the battery you are buying

Step 6: Cross-check the product listing against your measurements

Before ordering, compare the battery’s listed:

length
width
height
terminal type
weight

against both the Group 31 baseline and your measured tray dimensions.

This is where most avoidable fit mistakes get caught.

Step 7: Confirm it is the right kind of replacement

Even after physical fit checks out, ask:

Do I need starting power, deep-cycle capacity, or both?
Does my charging system match the battery chemistry?
Is the weight realistic for my tray and for handling?
Will the terminals line up safely?

That last check matters because a battery can be the right case size and still be the wrong functional replacement.

Simple fit checklist

Use this quick checklist before buying any Group 31 replacement:

Measure tray length, width, and vertical clearance
Confirm hold-down style
Check terminal orientation and cable reach
Compare the exact product spec to the 13 × 6.8 × 9.4 in baseline
Allow for slight variation, especially in height
Verify battery type and purpose, not just case size

Final fit perspective

Group 31 is one of the easier battery sizes to shop because the footprint is consistent enough to narrow the field quickly. The last part of the decision is where buyers need to slow down.

The final check should always be:

exact product dimensions
terminal layout
hold-down compatibility
chemistry fit
application fit

That extra step is what turns “probably right” into “fits correctly.”

FAQ

What are the standard BCI dimensions for a Group 31 battery?

The most widely repeated reference size is about 13.0 inches long, 6.8 inches wide, and 9.4 inches high, commonly expressed as 330 × 173 × 240 mm. Published listings vary slightly, but that is the clearest overall baseline.

Is there a difference in dimensions between lead-acid and lithium Group 31 batteries?

Often, yes. Lead-acid Group 31 batteries usually stay close to the traditional 13 × 6.8 × 9.4 inch envelope. Lithium Group 31 batteries often keep similar length and width but may be shorter in height, with published examples around 8.43 to 8.5 inches tall.

How much taller is a Group 31 battery than a Group 27?

As a practical rule, about half an inch taller. A common Group 27 reference is roughly 8.89 inches high, while Group 31 commonly appears around 9.44 inches high.

What is the typical weight of a Group 31 battery?

Typical weight depends on chemistry:

Flooded lead-acid: about 60–75 lb
AGM: about 62–72 lb
Lithium: about 22–35 lb

So two Group 31 batteries can share the same basic size family and still feel very different to install.

Can all Group 31 batteries be used interchangeably?

No. Many are physically similar enough to fit the same tray, but they are not automatically interchangeable. You still need to verify:

terminal layout and polarity
hold-down compatibility
chemistry and charging compatibility
whether the battery is intended for starting, deep-cycle use, or dual-purpose duty

A Group 31 label is a strong fit clue, not a full replacement guarantee.
